LangGraph 101: Building Your First Stateful Agent

Deep Dive: Stage 1 — LangGraph's Mental Model: Graphs, State, Nodes, and Edges

• Before writing any code, you need three clear ideas in your head.
• LangGraph is built from exactly these three concepts — nothing more.
• State is a Python dictionary typed with TypedDict .
• Every node in the graph can read it and write partial updates to it.

Observable outcome: Every node in the graph can read it and write partial updates to it.

Deep Dive: Stage 2 — Building Blocks: TypedDict State, Nodes, and How Edges Connect Them

• Let's make everything above concrete with runnable code.
• Here is the minimum viable LangGraph agent — a two-node graph that greets a user and then summarizes the greeting.
• Step 1 — Define your state schema with TypedDict The Annotated[list[str], operator.add] syntax is the first thing that surprises most developers.
• When a node returns {"messages": ["Hello!"]} , LangGraph does not replace the entire messages list — it appends to it.

from typing import Annotated
from typing_extensions import TypedDict
import operator

class AgentState(TypedDict):
    messages: Annotated[list[str], operator.add]
    # operator.add means "append new values; never overwrite the whole list"

def greet_node(state: AgentState) -> dict:
    """Add a greeting to the message list."""
    return {"messages": ["Hi! How can I help you today?"]}

def summarize_node(state: AgentState) -> dict:
    """Summarize everything that has been said so far."""
    history = " | ".join(state["messages"])
    return {"messages": [f"[Summary]: {history}"]}

Observable outcome: When a node returns {"messages": ["Hello!"]} , LangGraph does not replace the entire messages list — it appends to it.

Deep Dive: Stage 3 — Deep Dive: How LangGraph Compiles and Executes Your Graph

• The Internals: Pregel-Style Execution Under the Hood When you call StateGraph.compile() , LangGraph validates the graph structure (checks for disconnected nodes, missing entry points, unreachable END ) and produces an e…
• At each superstep, LangGraph identifies the currently active nodes, runs them, collects their partial state updates, and merges those updates into the shared state dict before advancing to the next step.
• The merge strategy for each field is controlled by its annotated reducer — operator.add for append, or overwrite-by-default for unannotated fields.
• LangGraph also serializes the full state after each superstep.

from langgraph.checkpoint.memory import MemorySaver

checkpointer = MemorySaver()
graph = builder.compile(checkpointer=checkpointer)

# Each run gets a thread_id — state is persisted per thread
config = {"configurable": {"thread_id": "user-session-42"}}
result = graph.invoke({"messages": []}, config=config)

for step in graph.stream({"messages": []}):
    node_name = list(step.keys())[0]
    print(f"✅ Node '{node_name}' completed: {step[node_name]}")

Observable outcome: LangGraph also serializes the full state after each superstep.

Deep Dive: Stage 4 — Your First Agent: A Research Assistant That Can Search

• Now let's build the worked example.
• The agent takes a user question, decides whether it needs to search the web before answering, runs a search if needed, and synthesizes the final response.
• Here is the graph structure: The router LLM inspects the question and sets a needs search flag.
• If true, the search node runs and injects results into state.

graph TD
    A([ User Question]) --> B[router_node Decide: search needed?]
    B -->|needs_search = true| C[search_node Fetch results]
    B -->|needs_search = false| D[answer_node Synthesize answer]
    C --> D
    D --> E([END])

    style A fill:#e3f2fd,stroke:#1976D2,color:#000
    style E fill:#e8f5e9,stroke:#388E3C,color:#000
    style B fill:#fff8e1,stroke:#F57F17,color:#000
    style C fill:#f3e5f5,stroke:#7B1FA2,color:#000
    style D fill:#e8f5e9,stroke:#2E7D32,color:#000

import operator
from typing import Annotated
from typing_extensions import TypedDict
from langchain_openai import ChatOpenAI
from langchain_core.messages import HumanMessage, AIMessage, BaseMessage
from langgraph.graph import StateGraph, END

# --- 1. State schema ---
class ResearchState(TypedDict):
    messages: Annotated[list[BaseMessage], operator.add]
    search_results: str
    needs_search: bool

# --- 2. LLM (swap freely — see the LLM-agnostic section below) ---
llm = ChatOpenAI(model="gpt-4o-mini", temperature=0)

# --- 3. Node: decide whether to search ---
def router_node(state: ResearchState) -> dict:
    question = state["messages"][-1].content
    prompt = (
        f"Does answering this question require current web information?\n"
        f"Question: {question}\n"
        f"Reply with only: YES or NO"
    )
    response = llm.invoke([HumanMessage(content=prompt)])
    return {"needs_search": "YES" in response.content.upper()}

# --- 4. Node: run the search ---
def search_node(state: ResearchState) -> dict:
    question = state["messages"][-1].content
    # Replace this stub with TavilySearch, Serper, or Bing API in production
    results = f"[Search stub] Top results for: '{question}' — relevant facts retrieved."
    return {"search_results": results}

# --- 5. Node: synthesize the answer ---
def answer_node(state: ResearchState) -> dict:
    context_messages = list(state["messages"])
    if state.get("search_results"):
        context_messages.append(
            HumanMessage(content=f"Use this context to answer: {state['search_results']}")
        )
    context_messages.append(HumanMessage(content="Now answer the original question."))
    response = llm.invoke(context_messages)
    return {"messages": [AIMessage(content=response.content)]}

# --- 6. Routing function ---
def route_search(state: ResearchState) -> str:
    return "search_node" if state.get("needs_search") else "answer_node"

# --- 7. Build and compile the graph ---
builder = StateGraph(ResearchState)

builder.add_node("router_node", router_node)
builder.add_node("search_node", search_node)
builder.add_node("answer_node", answer_node)

builder.set_entry_point("router_node")
builder.add_conditional_edges("router_node", route_search, {
    "search_node": "search_node",
    "answer_node": "answer_node",
})
builder.add_edge("search_node", "answer_node")
builder.add_edge("answer_node", END)

graph = builder.compile()

# --- 8. Run it ---
result = graph.invoke({
    "messages": [HumanMessage(content="What is the current price of Bitcoin?")],
    "search_results": "",
    "needs_search": False,
})
print(result["messages"][-1].content)

Observable outcome: If true, the search node runs and injects results into state.

Deep Dive: Stage 5 — Real-World Applications: Where Stateful Graphs Show Up in Production

• LangGraph is not a toy framework.
• Stateful graphs power several real production patterns: Customer support routing — A support bot classifies incoming messages: simple FAQs route directly to an answer node; complex issues enter a multi-turn diagnostic l…
• State tracks the conversation history, the issue category, and an escalation flag across every turn without external session storage.
• Code generation with self-repair — An agent generates code, runs a linter node, reads the linter output from state, and conditionally loops back to the LLM to fix errors.

Observable outcome: Code generation with self-repair — An agent generates code, runs a linter node, reads the linter output from state, and conditionally loops back to the LLM to fix errors.

Deep Dive: Stage 6 — Practical Example: Making the Graph LLM-Agnostic

• One of LangGraph's cleanest design decisions is that nodes are plain Python functions with no opinion about which LLM you use.
• Swapping providers requires changing exactly one line — the llm assignment at the top.
• This scenario was chosen because it is the most common "day 2" question new LangGraph users ask — and showing it is a one-liner is the best answer.
• As you read through the three provider options, watch how every other line (the research node , the StateGraph , the compile() call) stays identical across all three — that invariance is LangGraph's LLM-agnostic promise…

# Option 1: OpenAI — best default for production
from langchain_openai import ChatOpenAI
llm = ChatOpenAI(model="gpt-4o-mini", temperature=0)

# Option 2: Anthropic Claude — great for long-context reasoning
from langchain_anthropic import ChatAnthropic
llm = ChatAnthropic(model="claude-3-haiku-20240307", temperature=0)

# Option 3: Ollama — fully local, zero API cost, great for development
from langchain_ollama import ChatOllama
llm = ChatOllama(model="llama3.2", temperature=0)

# The graph, nodes, state schema, and edges are IDENTICAL for all three.

def make_router_node(llm):
    """Factory that binds a specific LLM into the router node."""
    def router_node(state: ResearchState) -> dict:
        question = state["messages"][-1].content
        prompt = f"Does answering this require web search?\nQuestion: {question}\nReply YES or NO"
        response = llm.invoke([HumanMessage(content=prompt)])
        return {"needs_search": "YES" in response.content.upper()}
    return router_node

# At graph build time, pick your LLM and inject it:
builder.add_node("router_node", make_router_node(llm))

Observable outcome: As you read through the three provider options, watch how every other line (the research node , the StateGraph , the compile() call) stays identical across all three — that invariance is LangGraph's LLM-agnostic promise…
