ACID Transaction Fundamentals

Core Mechanics: Relational databases sit atop volatile RAM (buffer pools) and block-oriented disks that can fail mid-write while hundreds of clients mutate overlapping rows concurrently.

Visual & Structural Flow: Depicts WAL + MVCC Commit & Crash-Recovery Architecture (SQL Client (txid=8421) -> Buffer Pool + MVCC -> pg_wal (Sequential) -> pg_xact + Heap Pages); Write Skew Under Snapshot Isolation vs. Serializable Detection (Tx 1 (Dr. Alice) -> MVCC Snapshot -> Tx 2 (Dr. Bob)); ACID Transaction & Retry State Machine (ACTIVE -> COMMITTED -> ABORTED (40001)).

Trade-Offs & Production: Choosing an isolation level or coordination model trades throughput against anomaly prevention. High-throughput payment and order systems combine NVMe-backed WAL group commit (commit_delay batching multiple concurrent COMMITs into a single fsync) with the Transactional Outbox pattern.

Failure Modes & Application: Explore how ACID internals—MVCC snapshots, gap locks, XID wraparound, and transactional outboxes—manifest in real production incidents and system designs.
